Concrete Floor Grinding Machine Four Planetary Grinding Plates
HW-G10 concrete grinder is a four head planetary machine. The Grinding width is 650mm, 11hp, for 220v or 380v. G10 improves 30% working productiveness than three heads planetary grinding machine, as it is still planetary design but has a more head;
Application:
Grinding and finishing of resin based and tiled terrazzo
Provides ideal preparation for thin film coating
Parameters
| Voltage | 220-240V ,1P/3phrase | 380V-440V, 3phrase |
| Frequency | 50/60HZ | 50/60HZ |
| Current | 26.7A | 15.5A |
| Power Output | 10hp(7.5KW) | 10hp(7.5KW) |
| Inverter power | 15hp(11KW) | 15hp(11KW) |
| Motor speed | 300-1800rpm | 300-1800rpm |
| Grinding width | 650mm | 650mm |
| Disc Dianeter | 250mm*4plate | 250mm*4plate |
| N.W | 270KG | 270KG |
| Water Tank | 30L | 30L |
| Dimension | 970*650*950mm | 970*650*950mm |
Features
The reversing switch changes the direction of rotation of the motor.
Low center of gravity design, smoother operation.
The machine frame is made up of high strength steel body, good for anti-vibration
Contrast
gear box is smooth and clean exquisite craftwork
gear box is coars even the dregs are left by parts processing
Bearing is NSK, made in Japan, famous bearing name.
Chinese bearings, the quality is not as goodas that of Japan brand
Famous brand TTO seal made in Taiwan
No brand. notimported seal
Poly urethane rubber pads, the flexibility is adjusted many times, for long life
Common material. theflexibility is not enough, easy to break
High strengthsteel. hard, solid
Common strengthsteel. even rust
High grade gear hobbin high-accuration
Not high grade gear hobbing,not high-accuration
Company introduction
Changsha Honway Machinery Co., Ltd is the professional manufacturer for floor scarifying & grinding & polishing machine in China. We are located in Changsha city which is well known as the capital of construction machinery in China. This city has the abundant supply of machinery engineers, workers, technique, workcraft, etc. Our company develops here and builds up as a manufacturing the machines for ‘Concrete Superflat floor’.
After Sell Service
- One year of warranty for machine.
- We always supply the consumables.
- We always supply the spare parts for all the old models.
- The spare parts can be sent out immediately at any time, delivered by DHL.
- The CD and operation manual is sent with machine to guide the installation process works and repair problems.
- All machines are tested, and the testing record will be kept, before it leaves factory.
- If the customers visit our factory, we could provide the training lessons.
FAQ
Q: Where is your factory?
A: It is located in Changsha, Hunan province. Welcome you come to our factory and produce process at any time.
Q: What kind of machine you supply?
A: Concrete grinding machine, concrete scarifying machine, diamond tools.
Q: What voltage of your machine?
A: 380V three phase,220V three phase and 220V single phase.
Q: What certificates of your machine?
A: 3C CE SGS
